Wolf DF366 - Installation Types

106 | Wolf Customer Care 800.222.7820
11
3
/4"
(298)
OPENING
HEIGHT
DOORS / DRAWERS
OPENING WIDTH
24
1
/4" (616)
OPENING
DEPTH
OPENING
HEIGHT
6"
(152)
1" (25) min
GRILL
OPENING
13
/16"
(21)
COUNTERTOP
OVERHANG
GRILL
OVERLAP
FRONT VIEW
TOP VIEW
W
OPENING WIDTH
NOTE: Shaded area above countertop indicates minimum clearance to
combustible surfaces, combustible materials cannot be located within this area.
2
1
/2" (64)
13"
(330)
3
1
/2"
(89)
G
4"
(102)
6"
(152)
G
12
5
/8"
(321)
OPENING
HEIGHT
DOORS / DRAWERS
OPENING WIDTH
26" (660)
OPENING
DEPTH
OPENING
HEIGHT
12"
(305)
1" (25) min
10
3
/4"
(273)
5"
(127)
C
L
C
L
2
3
/4" (70)
KNOCKOUT
LINER
OPENING
13
/16"
(21)
COUNTERTOP
OVERHANG
LINER
OVERLAP
FRONT VIEW
TOP VIEW
W
OPENING WIDTH
NOTE: Shaded area above countertop indicates minimum clearance to
combustible surfaces, combustible materials cannot be located within this area.
12" (305)
G
WOLF OUTDOOR GRILLS
OPENING WIDTH
NON-COMBUSTIBLE ENCLOSURE W
OG30 28
1
/2" (724)
OG36 34
1
/2" (876)
OG42 40
1
/2" (1029)
OG54 52
1
/2" (1334)
Outdoor Grills
NON-COMBUSTIBLE INSTALLATION COMBUSTIBLE INSTALLATION
RANGES / RANGETOPSVENTILATION COOKTOPS / COFFEE SYSTEMS OVENS / WARMING DRAWERSOUTDOOR GRILLS
OPENING WIDTH
COMBUSTIBLE ENCLOSURE W
OG30 33
1
/2" (851)
OG36 39
1
/2" (1003)
OG42 45
1
/2" (1156)
OG54 57
1
/2" (1461)
