FRONT VIEWSIDE VIEW
*1" (25) minimum depth. Shaded areas will be visible and should be finished to match cabinetry.
**
7
/8" (22) for professional and transitional models and 1" (25) for contemporary model.
***Dimension provides minimum reveals.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
28
3
/4"
(730)
FLUSH INSET
HEIGHT***
1
1
/8" (29)
1
/8" (3)
13
/16" (21)
24" (610)
FLUSH INSET
DEPTH
7
/8" (22)
OR
1"(25)**
60
1
/8" (1527)
FLUSH INSET WIDTH***
TOP VIEW
EE
FINISHED
CLEATS*
Dual M Series Ovens
FLUSH INSET INSTALLATION
WOLF BUILT-IN OVENS
