WOLF BUILT-IN OVENS
30" E Series Double Oven
FLUSH INSET INSTALLATION
E
5"
(127)
4"
(102)
E
E
FRONT VIEWSIDE VIEW
*Will be visible and should be finished to match cabinetry.
**1"
(25) for professional and transitional models and 1
1
/4" (32) for contemporary model.
***Dimension provides minimum reveals.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
50
7
/8"
(1292)
FLUSH INSET
HEIGHT***
17" (432)
TYPICAL
3
/4"(19)
3
/8" (10)
15
/16" (24)
30
3
/8" (772)
FLUSH INSET WIDTH***
25" (635)
FLUSH INSET
DEPTH
1" (25)
OR
1
1
/4" (32)**
TOP VIEW
FINISHED
CLEATS*
