Wolf DF486G - 30 E Series Oven Installation

26 | Wolf Customer Care 800.222.7820
WOLF BUILT-IN OVENS
E
5"
(127)
4"
(102)
FRONT VIEWSIDE VIEW
28
3
/8"
(721)
FLUSH INSET
HEIGHT***
3
/4"(19)
3
/8" (10)
15
/16" (24)
25" (635)
FLUSH INSET
DEPTH
30
3
/8" (772)
FLUSH INSET WIDTH***
1" (25)
OR
1
1
/
4
"
(32)**
TOP VIEW
39" (981)
TYPICAL
E
E
FINISHED
CLEATS*
*Will be visible and should be finished to match cabinetry.
**1"
(25) for professional and transitional models and 1
1
/4" (32) for contemporary model.
***Dimension provides minimum reveals.
NOTE: Location of electrical supply within opening may require additional cabinet depth.
30" E Series Single Oven
FLUSH INSET INSTALLATION
