Planning Information
Model MW24 Non-Convection Microwave Oven
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions, rough openings and
installation specifics.
The Wolf non-convection microwave oven
can be used free-standing or with optional 30"
(762) trim, can be built in to fit above a Wolf
30" (762) built-in single oven. The base
platform must be able to support 125 lbs
(57 kg).
IMPORTANT NOTE: In all instances, where
the microwave oven is built in, you must use
the Wolf 30" (762) trim kit to ensure proper
ventilation.
The trim kit for the Wolf non-convection
microwave oven will overlap cabinetry stiles
and rails on all four sides. The trim overlaps
13
/16" (21) on the bottom,
7
/16" (11) on the top
and 1
3
/16" (30) on each side.
Refer to the installation instructions provided
with the trim kit for detailed specifications.
These instructions can also be found on the
Wolf website at wolfappliance.com.
When using the Wolf microwave oven as a
free-standing unit, allow 2" (51) of airflow
space on top, rear and both sides. A minimum
20" (508) cabinet depth is required.
The Wolf non-convection microwave oven
requires a separate, grounded 120 V AC, 60 Hz
power supply. The service should have its own
15 amp circuit breaker and a grounded 3-prong
receptacle should be located within the reach of
the 3' (.9 m) power cord. Locate electrical
within the shaded area shown in the Installation
illustration.
IMPORTANT NOTE: A ground fault circuit
interrupter (GFCI) is not recommended and may
cause interruption of operation.
The Wolf non-convection microwave oven
with trim may be installed in combination with
a 30" (762) built-in single oven and/or warming
drawer. Refer to page 6 for additional installa-
tion specifications.
You must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
Refer to the installation instructions
shipped with each Wolf product for detailed
specifications.
DIMENSIONS
Rough Opening Width 27
1
/2" (699)
Rough Opening Height 17" (432)
Rough Opening Depth (minimum) 20" (508)
Recommended Cabinet Width 33" (838)
Minimum Cabinet Width 30" (762)
Location of Electrical Within shaded area
See Installation Instructions shipped with unit for detailed specifications.
