Using extension cables
See Section 3 Setting up the Compressor
WARNING! Use recommended high
pressure hoses and couplings High
pressure hoses, fi ttings and couplings are
important for the safety of the appliance.
Use only hoses, fi ttings and couplings de
signed for usage with air compressors.
Before disconnecting the air hose from the compres-
sor For safety discharge residual pressure in the air
hose before disconnecting.
Using the compressor with your air tools Before us-
ing the compressor and your air tools, CHECK every
time that the connections are fully tightened and that
there are no broken or worn parts. Always adhere to
the processes and safety warnings, which are stated
in the instructions of your air tools.
Guard against electric shock
Use an RCD (residual current device) to provide pro-
tection against electrical shock. Consider the work
environment
Make sure the area is clear of obstacles, which could
cause you to trip and fall.
Before moving the compressor
The compressor air receiver must be discharged be-
fore the machine is transported.
Keep work area clean
Cluttered areas invite injuries.
3 - SETTING UP THE COMPRESSOR
---------------------------------------------------------------------
Important: Only use the compressor for the
purpose for which it was designed.
The compressor is designed for use as stated only;
do not attempt to adapt it for other purposes .The
manufacturer assumes no responsibility for any
damages resulting from improper use for noncompli-
ance with the instructions described in this
manual. The compressor is for use by competent
persons only.
Before Operation
Check package contents
Check for damage
Before using this item check each part is undam-
aged. Check all pipes are fi rmly connected. Check
plastic covers for damage. Inspect the air receiver
(tank) to ensure that it has not been damaged.
Save packaging
Save major packaging for return of product in the
event of service or repair.
Electrical supply
Before using the air compressor please check that
you have a suitable electrical supply to support the
requirements of the motor unit. Please ensure your
mains power supply corresponds to the power rating
on the data label on the machine.
Electrical Cables
Ensure that all cables are damage free before con-
necting to the power supply.
Using Extension Cables
Use an extension cable, which is no more than
10metres long and has a conductor cross-section
of at least 1.5mm2 i.e. a heavy-duty cable. Using
an excessively long or thin-wired extension cable
will cause severe damage to the motor Always fully
unwind extension cables. If using extension cables
outdoors always use a cable , which is marked for
outdoor use.
Always maintain a clear area around the compres-
sor It is very important that the compressor is posi-
tioned so that there is an adequate airfl ow around
the machine. The compressor should be situated so
that it has 50cm of obstacle free space around its air
receiver (tank) and pump/motor unit.
!
TROUBLESHOOTING GUIDE (CONT)
-----------------------------------------------------------------------------------------------------------------------------------------------
Symptom Possible Cause (s) Corrective Action
-----------------------------------------------------------------------------------------------------------------------------------------------
Compressor runs 1. Excessive air usage compressor 1. Decrease usage or purchase
continuously and air output is too small unit with higher air delivery (CFM)
lower than normal/low 2. Clogged intake fi lter 2. Clean or replace
discharge pressure 3. Air leaks in piping (on machine 3. Replace leaking components
or in outside system) or tighten as necessary
4. Broken inlet valves 4. Replace compressor valves
5. Piston ring worn 5. Replace piston and cylinder
-----------------------------------------------------------------------------------------------------------------------------------------------
Excessive moisture in 1. Excessive water in tank 1. Drain tank
discharge air 2. High humidity 2. Move to area of less humidity; use
air line fi lter
NOTE: Water condensation is not
caused by a malfunction in the
compressor
-----------------------------------------------------------------------------------------------------------------------------------------------
Compressor runs continuously 1. Defective pressure switch 1. Replace switch
and safety valve opens as 2. Defective safety valve 2. Replace safety valve with genuine
pressure rises replacement part
-----------------------------------------------------------------------------------------------------------------------------------------------
Excessive starting and Excessive condensation in tank Drain more often
stopping (auto start)
-----------------------------------------------------------------------------------------------------------------------------------------------
Air leaking from unloader No-return valve stuck in an Remove and replace no-return valve
on pressure switch open position DANGER! Do not disassemble non return
valve with air in tank; bleed tank fi rst
