Wolf SO30F/S - Page 88

Wolf Outdoor Grills and Modules 88
Outdoor Grill Installation (Built-In)
NON-COMBUSTIBLE ENCLOSURE
36"
(914)
OPENING WIDTH
TOP VIEW
FRONT VIEW
11
3
/4"
(298)
OPENING
HEIGHT
6"(152) min TO
NON-COMBUSTIBLE
SIDE SURFACES
6"(152) min TO
NON-COMBUSTIBLE
SIDE SURFACES
OPENING WIDTH
FOR ACCESSORY DOORS
OR DRAWERS
OPENING
HEIGHT
1" (25) min
24
1
/4"
(616)
OPENING
DEPTH
2
1
/2" (64) min
TO NON-COMBUSTIBLE REAR SURFACES
FOR HOOD CLEARANCE
COUNTERTOP
OVERHANG
OPENING
FOR GRILL
13
/16"
(21)
13"
(330)
3
1
/2"
(89)
G
4"
(102)
6"
(152)
G
GRILL
OVERLAP
36"
(914)
OPENING WIDTH
TOP VIEW
12
5
/8" (321)
OPENING
HEIGHT
OPENING WIDTH
FOR ACCESSORY DOORS
OR DRAWERS
26"
(660)
OPENING
DEPTH
OPENING
HEIGHT
12" (305) min
TO COMBUSTIBLE REAR SURFACES
12" (305) min TO
COMBUSTIBLE
SIDE SURFACES
12" (305) min TO
COMBUSTIBLE
SIDE SURFACES
1" (25) min
OPENING
FOR LINER
13
/16"
(21)
10
3
/4"
(273)
5"
(127)
C
L
C
L
2
3
/4" (70)
KNOCKOUT FOR
GAS SUPPLY
FRONT VIEW
COUNTERTOP
OVERHANG
LINER
OVERLAP
COMBUSTIBLE ENCLOSURE WITH LINER
Optional Opening
ACCESSORY DOORS W H
18" (457) Single 16
1
/4" (413) 19" (483)
30" (762) Double 28
1
/4" (718) 19" (483)
36" (914) Double 34
1
/4" (870) 19" (483)
42" (1067) Double 40
1
/4" (1022) 19" (483)
54" (1372) Double 52
1
/4" (1327) 19" (483)
ACCESSORY DRAWERS W H
30" (762) Single 27
1
/4" (692) 9
3
/4" (248)
13" (330) Double 12
1
/8" (308) 19" (483)
13" (330) Triple 12
1
/8" (308) 19" (483)
30" (762) Double with Door 29
1
/4" (743) 19" (483)
Opening Width
NON-COMBUSTIBLE ENCLOSURE W
Model OG30 28
1
/2" (724)
Model OG36 34
1
/2" (876)
Model OG42 40
1
/2" (1029)
Model OG54 52
1
/2" (1334)
COMBUSTIBLE ENCLOSURE W
Model OG30 33
1
/2" (851)
Model OG36 39
1
/2" (1003)
Model OG42 45
1
/2" (1156)
Model OG54 57
1
/2" (1461)
