Wolf Cooktop Ventilation 94
Cooktop Wall Hood
INSTALLATION
21" (533)
DEPTH OF HOOD
30" (762) OR 35
7
/16" (900)
WIDTH OF HOOD
30
1
/2" (775) TO 48
1
/2" (1232)
OR
32
11
/16" (830) TO 50
7
/8" (1292)
HEIGHT OF HOOD
E
4" (102)
6"
(152)
LOCATION OF
ELECTRICAL
24" (610) TO 30" (762)
TO COUNTERTOP
9"
(229)
FRONT VIEWSIDE VIEW
