Wolf Sub-Zero ICBIG15/S - Page 59

59
WOLF COOKTOP VENTILATION
SPECIFICATIONS
Model ICTEWH30I
Hood Type Wall Hood
Overall Width 762 mm
Overall Height 80 mm
(excluding chimney)
Overall Height 790 mm
(including chimney)
Maximum Height 1210 mm
(full extension)
Overall Depth 450 mm
Bottom of Hood
to Countertop 650 mm to 760 mm
Duct Size 150 mm Round
Discharge Vertical
Internal Blower 500 CFM included
Electrical Supply 220-240 V AC, 50/60 Hz
15 amp dedicated circuit
Shipping Weight 18 kg
(shell only)
SPECIFICATIONS
Models ICTEWH36 and ICTEWH36I
Hood Type Wall Hood
Overall Width 914 mm
Overall Height 80 mm
(excluding chimney)
Overall Height 790 mm
(including chimney)
Maximum Height 1210 mm
(full extension)
Overall Depth 450 mm
Bottom of Hood
to Countertop 650 mm to 760 mm
Duct Size 150 mm Round
Discharge Vertical
Internal Blower 500 CFM included with
Model ICTEWH36I
Blower Options Contact your
Wolf dealer
Electrical Supply 220-240 V AC, 50/60 Hz
15 amp dedicated circuit
Shipping Weight 21 kg
(shell only)
*Blower options vary with the cooking
surface. Refer to the cooktop ventilation
recommendations on pages 68–69.
762 mm
OVERALL WIDTH
450 mm
OVERALL DEPTH
510 mm
80 mm
200 mm
TO
620 mm
250 mm 274 mm
790 mm
TO
1210 mm
OVERALL
HEIGHT
OVERALL DIMENSIONS
E Series Cooktop Wall Hoods
Model ICTEWH30I
OVERALL DIMENSIONS
E Series Cooktop Island Hood — Model ICTEIH42
914 mm
OVERALL WIDTH
450 mm
OVERALL DEPTH
510 mm
80 mm
200 mm
TO
620 mm
250 mm 274 mm
790 mm
TO
1210 mm
OVERALL
HEIGHT
Models ICTEWH36 and ICTEWH36I
1143 mm
OVERALL WIDTH
450 mm
OVERALL DEPTH
510 mm
80 mm
200 mm
TO
620 mm
250 mm 274 mm
790 mm
TO
1210 mm
OVERALL
HEIGHT
Model ICTEWH45
1067 mm
OVERALL WIDTH
550 mm
OVERALL DEPTH
488 mm
80 mm
222 mm
TO
642 mm
297 mm 251 mm
790 mm
TO
1210 mm
OVERALL
HEIGHT
