– 8 –
ELECTRICAL CONNECTIONS
Electrical and grounding connections must comply with the applicable
portions of the National Electrical Code and/or other local electrical codes.
Appliances equipped with a flexible electric supply cord are provided with
a three-prong grounding plug. It is imperative that this plug be connected into a properly
grounded three-prong receptacle. If the receptacle is not the proper grounding type,
contact an electrician. Do not remove the grounding prong from this plug.
WKG series ovens with 120 V/60 Hz/1 PH electrical specification are equipped with a cord and plug
as standard equipment.
A wiring diagram is located on the inside of the control housing.
Minimum Circuit Ampacity
Model V/Hz/PH Maximum Protective Device
AMPS
120/60/1 15
208/60/1 (Opt.) 15
240/60/1 (Opt.) 15
WKGD 240/50/1 (Opt.) 15
220/380 (3W)/50/3 (Opt.) 15
220/380 (4W)/50/3 (Opt.) 15
240/415 (4W)/50/3 (Opt.) 15
ELECTRICAL DATA
Compiled in accordance with the National Electrical Code, NFPA-70 (latest edition).
