R
VISUALIZER
VZ-3
ZOOM
Components of the Visualizer
#2
#1
#3
#4
#1 Working surface (see page 7)
#2
#3 Light (maintenance-free LED)
#4 Control keys (see next page)
Connectors (on the back behind the cable cover - see below)
Zoom wheel (see next page)
3
Connectors (#2)
#5 DVI-I output (see page 8)
#6 USB port (see page 7)
External Input for Computer RGB-signals (15pin)
10/100 TBase
#7 (see page 9)
#8 LAN port (see page 7)
Power connection PoE+ (see page 7)
#9 Cable Tie to fix all cables (to unfasten, press the lug)
#5
LAN (PoE+)
EXTERN IN
USB
DVI
#6
#8
#7
#9
