Wood-mizer SW-10 SETWORKS User Manual

INSTALLATION
SW-10 Controller Installation Procedure on the LT15 Sawmills
INSTALLATION SW-10doc111419 1-1
1
SECTION 1 INSTALLATION
1.1 SW-10 Controller Installation Procedure on the LT15 Sawmills
IMPORTANT! Make sure the sawmill is properly set up
before performing setworks installation and/or operation.
WARNING! Before performing any service to the sawmill
control box panel, turn the key to the “0”. Set the main
switch, located on the control box in “0” position and
disconnect the power supply cable. In DC sawmills unplug
the battery cables. Failure to do so may cause serious
injury and machine damage.
1. Replace the control panel bracket.
2. Mount the controller box to the bracket.

Wood-mizer SW-10 SETWORKS Specifications

General

Brand	Wood-mizer
Model	SW-10 SETWORKS
Category	Controller
Language	English
