Woodbridge Dreams Solid Slats - Page 6

Solid slat assembly
Use Pack 'X'
1
Identify the slat system you have purchased...
Standard wooden slat system.
Place the fixed wood slats onto the slat holders
on side rails "C".
Fix the slats at both ends and the middle using
bolts "F" , sleeve nuts "G", tighten with ke "I".
F
H
G
I
I
Woodbrige Double Bed - Assembly - Page 7
Solid slat assembly
Identify the slat system you have purchased...
Standard wooden slat system
Place the fixed wood slats onto the slat holders on side
rails"C".
Fix the slats at both ends and the middle using bolts "F",
sleeve nuts "G", tighten with allen key "I"
Woodbridge Single Bed - Assembly Guide - Page 6
Use Pack:
G
H
I
1
