Woodbridge Dreams Solid Slats - Page 7

Sprung slat assembly
Use Pack 'X'
3
Turn the metal slat frame falling upward and
carefully lower the slat frame into the bed.
Ensure that the frame sits on the guides located
on the side rails "C".
Position the slat frame so that the holes in the
side rail "C".
Position the slat frame to the side rails "C" by
threading bolt "F" through the holes in the frame
and the side rails "C".
Finally, tighten bolt "F" into the sleeve nut "G"
from the top of slats frame with allen key "I".
F
H
G
I
I
Woodbrige Double Bed - Assembly - Page 10
Sprung slat assembly
Turn the metal slat frame falling upward and carefully lower
the slat frame into the bed.
Ensure that the frame sits on the guides located on the side
rails "C"
Position the slat frame so that the holes in the side rail "C".
Secure the frame to the side rails "C" by threading bolt "F"
through the holes in the frame and the side rails "C".
Finally, tighten the bolt "F" into the sleeve nut "G" from the
top of slats frame with allen key 'I".
Woodbridge Single Bed - Assembly Guide - Page 7
Use Pack:
F
G
H
I
1
