Woods DS8.30E User Manual

Introduction 3
MAN1256 (3/23/2018)
TABLE OF CONTENTS
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GENERAL INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY DECALS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
OWNER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
DEALER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ASSEMBLY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
DEALER CHECK LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
INDEX TO PARTS LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
BOLT TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
BOLT SIZE CHART & ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
REPLACEMENE PARTS WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
PRODUCT WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
SPECIFICATIONS
GENERAL INFORMATION
 Some illustrations in this manual show the equipment with safety
shields removed to provide a better view. This equipment should never
be operated with any necessary safety shielding removed.
The purpose of this manual is to assist you in operating and maintaining your
cutter. Read it carefully. It furnishes information and instructions that will help
you achieve years of dependable performance. These instructions have been
compiled from extensive field experience and engineering data. Some informa-
tion may be general in nature due to unknown and varying operating condi-
tions. However, through experience and these instructions, you should be able
to develop procedures suitable to your particular situation.
The illustrations and data used in this manual were current at the time of print-
ing but, due to possible inline production changes, your machine may vary
slightly in detail. We reserve the right to redesign and change the machines as
may be necessary without notification.
Throughout this manual, references are made to right and left directions. These
are determined by standing behind the equipment facing the direction of for-
ward travel. Blade rotation is clockwise (right) and counterclockwise (left) as
viewed from the top of the cutter.
DS8.30E DS10.40E
Cutting Height 51 - 305 mm (2" - 12")
Cutting Width 2,4 m (96") 3,0 m (120")
Overall Width 2,6 m (100.5") 3,2 m (124.5")
Overall Length: Pull-Type (25" Tires) 3,6 m (142") 3,9 m (155")
Overall Length: Mounted 2,4 m (96") 2,7 m (106")
Minimum Tractor HP: Pull-Type 26 kW (35 HP) 30 kW (40 HP)
Minimum Tractor HP: Mounted 34 kW (45 HP) 45 kW (60 HP)
Tractor PTO RPM 540
Number of Blade Spindles 2
Blade overlap 101.6 mm (4")
Number of Blades 4
Driveline w/Slip Clutch: Pull-Type Cat 4 CV Cat 4 CV
Driveline w/Slip Clutch: Mounted Cat 4 Cat 5
Side Frame Thickness 4,5 mm (7 Ga) 4,5 mm (7 Ga)
Weight (w/Belting): Pull-Type 653 kg (1,440 lbs) 826 kg (1,820 lbs)
Weight (w/Belting): Mounted 551 kg (1,215 lbs) 714 kg (1,575 lbs)
Blade Speed (Per Minute) 4633 m (15,200 ft) 5090 m (16,700 ft)
Blade Rotation Left spindle: CCW; Right Spindle: CW
Wheel Size: Pull-Type 381 mm (15") Rims
533,4 mm (21") Laminated
635 mm (25") Severe Duty
Wheel Size: Mounted 406,4 mm (16") Laminated
Torsion Protection Slip Clutch and Flex Couplers
WARNING
