Woods RD990X - Lubrication Points & Chart

16 Owner Service
MAN0845 (1/12/2011)
Figure 10 . Lubrication Points & Chart
REF DESCRIPTION FREQUENCY
1 Driveline U-Joints 8 Hours
2 Gearbox (Fill to center of horizontal shaft with SAE 90W gear lube) Check for
leaks daily
3 Caster Wheel (Four Wheels) 8 Hours
4 Caster Pivot (Four Yokes) 8 Hours
5 Slip Joint 8 Hours
6 Shield Bearing 8 Hours
7 Blade Spindles (Access through hole) 8 Hours
(Rev. 10/1/2013)
