11�2 Specications
Frame
Frame
• Frame material: lightweight, high-quality 6061 T6 aluminium with butted and hyd-
roformed tubes
• 20˝/24˝/26˝wheelsize
• Sporty handling: an easy-access low top tube, low centre of gravity and long wheelbase
provide good balance and make for a fun, safe riding experience.
Fork
Fork
• woom OFF: lightweight carbon fork
• woom OFF AIR: Suspension fork, adjustable rebound , with lockout, 60 / 80 / 90 mm
suspension travel
• 11/8˝-1˝babytapershaft
• 100 x 15 mm through axle
• Post mount for disc brake
Headset
Headset
• Fullyintegrated11/8˝-1˝headset
• Sealed industrial bearings
Stem
• Forged aluminium
• CNC-machined
• Handlebars attached with two clamps and secured with four 4 mm internal hex screws
• +/-15°ip-opdesigntoadjusthandlebarheight
• Length: 50 mm
Handlebar
Handlebars
• Wide, ergonomically adapted and lightweight aluminium handlebars for more control
• Sandblasted and silver anodised
• Width: 580 / 600 / 680 mm
• Rise: 20 mm
Grips
Grips
• Child-friendly thanks to small diameter
• 100% silicon for maximum grip
• Non-toxic
• Handlebar ends with screwed-in end plugs
Crank
Drive
• Lightweight, forged 10 / 130 / 150 mm aluminium cranks with narrow tread (Q-factor)
• Narrow-wide chainring with 28 teeth in the front
• Cassette with 11 to 32 / 11 to 34 / 11 to 36 rear teeth
• Flatpedalsmadefrombre-reinforcednylon
• Cr-Mo axle and sealed industrial ball bearings
Brake
Brake
• Hydraulic disc brakes from Promax
• Rear/front disc diameter: OFF: 140/140 / 140/140 / 160/140 mm, OFF AIR: 160/140 mm
(any size)
• Ergonomic brake levers designed for children's hands
shifter
Gears
• 9 speeds
• SRAM X5 trigger shifter
• SRAM X5 rear derailleur
Rim
Wheels
• Superlight woom OFF DISCO TEC double-chamber aluminium rims
• Aluminium hubs with sealed industrial bearings
• Through axles for maximum torsional strength (100 x 15 mm front / 135 x 12 mm rear)
• With20˝and24˝:20G14spokes,double-crossedspoking
• with26˝:28G14spokes,triple-crossedspoking
• Aluminium nipples
Tire
Tyres
• 20x2.25˝/24x2.35˝/26x2.35˝SchwalbeRocketRonwithADDIXSPEEDrubber
compound
• Quality MTB tyres with low rolling resistance, maximum grip, good shock absorption
and excellent durability
• Car-typevalvesforeasyllingatanyservicestation
Saddle
Saddle
• Ergonomicallydesignedtotchildren'spelvis
• Non-toxic
• Side protection to lean against walls
Seatpost
Seatpost
• 27.2 x 250 / 27.2 x 250 / 27.2 x 300 mm
• Anodised aluminium seatpost with insertion marks that indicate the minimum in-
sertion depth
Saddle
clamp
• Made from aluminium
• No risk of turning and/or twisting
Tools
Enclosed
tools
• 4 mm hex key for stem and seatpost clamp
• 8 mm hex key for front wheel and pedals
Minimum
saddle
height
• OFF 580 / 705 / 780 mm, OFF AIR 590 / 715 / 780 mm
Size
Shipping
dimensions
• 115 x 65 x 23 / 132 x 70 x 23 / 145 x 78 x 23
light parts
Weight
• OFF: 7.8 / 8.6 / 9.3 kg (without pedals)
• OFF AIR: 9.0 / 10.1 / 11.0 kg (without pedals)
Colours
Colours
• Black
Weight
Weight
limits
• 50 / 70 / 80 kg (cyclist and luggage)
• 60 / 80 / 90 kg (cyclist, luggage and bike)
