Page #10 background imageLoading...
Page #10 background image
10
Fig. 11. Wiring diagram.
Fan
Flame sense
electrode
Air
pressure switch
Spark
electrode
Spark
transformer
Mains in
Link
Control Board
CH sensor
(front of heat
exchanger)
Flow
switch
ST16
2 blue
2 orange
2 brown
brown
blue
blue
brown
2 violet
white
2 red
2 yellow
2
pink
ST12
ST8
ST15
ST1
Pump
Gas valve
Reg
Main
Main
2 green
brown
yellow
Overheat cut-off
device
DHW sensor

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Worcester 25Si and is the answer not in the manual?

Worcester 25Si Specifications

General IconGeneral
Model25Si
CategoryBoiler
Output25 kW
Efficiency RatingA
Dimensions710mm x 400mm x 330mm
Fuel TypeNatural Gas
Flow Rate10.2 l/min
Boiler TypeCombi
MountingWall-mounted
ERP RatingA
DHW Output25 kW
Hot Water Flow Rate10.2 l/min
Max Working Pressure3 bar
Warranty5 years
CH Output25kW
