BATTERY CAPACITY INDICATOR
Battery capacity indicator
Press the battery capacity indicator switch.The battery
capacity indicator shows the charge status of the
battery using 4 LEDs.
All 4 LEDs are lit:
The battery is fully charged.
3 or 2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED blinks:
The battery is empty, recharge the battery.
All LEDs blink:
The battery pack is too hot (e.g. due to direct sunshine
or prolonged use) or too cold (below 32°F/0°C), Do not
use or charge the battery pack.make sure the battery
temperature to between 40°F(4°C) and 104°F(40°C).
Explanations and Actions
Indicator Status
Red LED Green LED
ON OFF
Ready for use
The charger is connected to the mains and is ready for use; there is no battery
pack in the charger
OFF
Quick
Blink
(2Hz)
Low-current saftey charging
As the battery pack voltage is under 15V,the charger is in gentle charging
mode,the charging current is below 0.5A.This can maximum the life of the
battery.
OFF
Slow
Blink
(1Hz)
High-current charging
As the battery pack voltage is above 15V,the charger is in quick charge
mode,the charging current is at 2.3-2.4A.
Important! The actual charging times may vary slightly from the stated charging
times depending on the existing battery charge.
OFF ON
The battery is charged and ready for use.
The battery is fully charged and ready to use..
Action: Take the battery pack out of the charger. Disconnect the charger from
the mains supply.
Quick
Blink
(2Hz)
OFF
Fault
Charging is no longer possible. The battery pack maybe defective.
Action:
Never charge a defective battery pack.Take the battery pack out of the charger.
Slow
Blink
(1Hz)
OFF
Temperature fault
The battery pack is too hot (e.g. due to direct sunshine/prolonged use) or too
cold (below 32°F / 0°C).
Action: Remove the battery pack and keep it at room temperature (approx. 68°F
/ 20°C) for 3 Hours.
CHARGER INDICATOR
MAINTENANCE
Clean the drill driver using a soft, damp cloth. Do
not use detergents or flam mable products which
may damage the tool.
Your cordless drill driver does not require regular
mechanical maintenance such as greasing the
bearings or the rollers.
Check the state of the charger power cable before
each use.
