TECHNICAL DATA
Description:
Elements:
Power Output:
Frequency Resp. (-3 dB):
Max. S.P.L.:
Connectors:
Insertion:
Dimensions (WxHxD):
Weight:
WPL BASS A
Powered Subwoofer
1x15" (Bass)
400 W RMS
45 Hz - 2 kHz
126 dB
35 mm.
485 x 711 x 436 mm.
35 Kg.
WPL BASS A
WPL Series (Passive) User Manual/Manual de Instrucciones Pag 5
EN
1
2
11
5
7
10
3
4
6
8
9
1. Volume Control.
2. ACTIVE LED. It lits when the amplified is turned
on.
3. Phase inversor switch
4. High Cut filter
5. LIMIT LED. Avoidconstant lighting (overload)
6. XLR3 output/link connector
7. XLR3 input connector
8. Power supply input. (Make sure that
the voltage selector is set for the correct
voltage).
9. 115 V/230 V Voltage input selector.
10. Protection fuse. Use only fuses of the
correct amp rating.
11. Power ON/OFF switch
DESCRIPTION
Input Impedance:
Sensitivity:
10 k? (MIC), 20 k? (LINE)
1,15V (+3.4 dBu)
XLR3 female + XLR3 male
