The quick-lock coupling (5) will click when the compressed air hose (9)
is disengaged.
WARNING: when releasing the quick-lock coupling, be sure to
hold the coupling piece to protect yourself against injury from
the rebounding hose.
2. To disconnect the air gun with pressure gauge (6) from the
compressed air hose (9), release the coupling connection by pulling the
sleeve on the coupling backwards and then remove the air gun inlet
connection (21) from the coupling connection. You will hear a click
when the air gun inlet connection (21) is disengaged.
3. To remove the hose with valve adapter/connector (10) from the air
gun with pressure gauge (6),screw the connection in an anti clockwise
direction until loose enough to remove.
NOTE: A 14mm spanner (not supplied) can also assist to loosen the
connection.
Assembly
