1. APPLICATION
This air pump is intended for inflating car and bicycle tyres, sports/gym balls and
the like. It is designed for domestic use and is not designed for commercial, trade
or industrial use.
WARNING! Please read and understand this instruction manual
before use and keep it for your future reference. Your power tool
should only be passed on together with this instruction manual.
2. PARTS DESCRIPTION
Fig.A
1. Air Chuck 9. Air Hose Storage Area
2. Adapter Storage Area 10. Air Hose
3. Battery (not included) 11. Air Chuck Clamp
4. Ball Needle Adapter 12. Digital Pressure Gauge
5. Tapered Universal Adapter 13. Pressure Setting (-)
6. Trigger Switch 14. Pressure Setting (+)
7. LED Worklight 15. Power and Mode Button
8. Air Hose Connector
12
15 14 13
1
7
6
5
4
8
9
11
10
2
3
