Workzone 99609 User Manual

Assembly
11
1. Place the chest
1
and base cabinet
2
upside down so that their bottom sides
are facing upwards.
2. Remove the four cross-head screws
15
on the bottom panel of the chest and
discard (see Fig. C).
3. Take out the bottom panel and fit it onto the bottom of the base cabinet. Further
secure it with two sets of M6 nuts
3
, M6 bolts (14 mm)
4
, M6 washers
5
and
round washers
14
at the rear (see Fig. D).
4. Line up the holes on the swivel casters
6
and casters with brake
7
with the
holes at the bottom corners. Secure the casters to the base panel and the bottom
of the base cabinet with four sets of M6 nuts, M6 bolts (14 mm) and M6 washers
(see Fig. E).
5. Stick the anti-scratch stickers
17
on the bottom of the chest (see Fig. F).
6. Place the chest on the base cabinet.
7. Align the brackets
10
with the screw holes of the chest and base cabinet and
secure each of them with two sets of screws
8
and M6 washers (see Fig. G).
8. Insert the handle
16
into the holes on the side of the base cabinet and further
secure it with four sets of M6 bolts (16 mm)
13
and M6 washers (see Fig. H).
The cabinet is now assembled.
Wall anchor
− To prevent the cabinet from tipping over, it is recommended to
secure the cabinet to a wall.
− A screwdriver
21
and an electric drill
22
are required for securing
the cabinet to a wall.
− Ensure that the positions where the drill holes are to be made are
free from pipes and other obstructions.
− It is suggested to mount the L-shaped bracket to a wall stud. If you
are mounting to a different wall type, consult your hardware store
for advice on the appropriate fixings to use.
1. Attach an L-shaped bracket
9
to the side of the base cabinet with
a screw (12 mm)
8
. Repeat on the other side (see Fig. I).
2. Attach the other end of the L-shaped bracket to the wall stud with
a wood screw (38 mm)
12
(see Fig. I). Repeat on the other side.
− For a different wall type, wall anchor
11
should be utilized. Drill the holes on the
wall aligning with the screw holes of the L-shaped bracket and place the wall
anchor inside the holes for securing the L-shaped bracket to the wall.
The cabinet is now mounted to the wall. Check the tightness of all connections before
use.
