3. Parts description
1. Handle
2. LCD screen.
3. Control Panel
4. AC adapter port
5. Auxiliary port
6. Antenna
7. Speaker
8. Battery compartment area
9. AC power adapter
10. “Volume” adjustment knob
11. “Tune” adjustment knob
12. Battery compartment latch
13. AA Battery back up compartment
(See Fig. C)
14. 20V Battery port (See Fig. D)
15. 20V Battery (See Fig. E)
16. Power button
17. USB Charging port (See Fig. I)
* 20V Battery and 20V Charger not included. Shown only for instructional purposes.
