6.4.3 Cutting width (Fig. 26 - 28)
• The parallel stop (7) has to be used when making longitudinal cuts in
wooden workpieces.
• The parallel stop (7) should be mounted on the right-hand side of the
saw blade (5).
• Place the parallel stop (7) on the guide rail for the parallel stop (12)
from above (Fig. 26).
• There are 2 scales (j/k) on the guide rail for the parallel stop (12)
which show the distance between the stop rail (e) and the saw blade
(5) (Fig. 27).
• Depending on this, choose the appropriate scale to suit whether the
stop rail (e) is turned for thick or thin material:
High stop rail (thick material): Scale j
Low stop rail (thin material): Scale k
• Set the parallel stop (7) for the required dimension using the
inspection window (I) and secure it using the eccentric lever for the
parallel stop (28).
6.4.4 Adjusting the stop length (Fig. 29)
• Set the required cutting width.
• The stop rail (e) can be moved in longitudinal direction in order to
prevent the workpiece from getting jammed.
• Rule of thumb: The rear end of the stop comes up against an
imaginary line that begins roughly at the center of the blade and runs
at an angle of 45° to the rear.
• Slacken the wing nuts (f) and push the stop rail (e) forward until it
touches the imaginary 45° line.
• Tighten the wing nuts (f) again.
