World Cat 2005 270 SD - Typical Digital Control Diagram

World Class Catamarans
3-7
TYPICAL DIGITAL CONTROL DIAGRAM
345678
1615141211
power
ground
3= RWATER 15A
4= ACC 1 / 10A
6= ACC 3 / 5A 5= ACC 2 / 5A
11= HORN / 10A 12= LWELL / 5A
8= STBDB / 5A 7= PORTB / 5A
16= KEYPAD (+) 15= N/A 10A 14= CPITL / 5A
LIVE
WELL
RAW
WATER
CPIT
LIGHTS
ACC
1
PORT
BILGE
STBD
BILGE
ACC
2
ACC
3
H O R N
L
T S
NAV
ANC
5A
10A 10A
20A 20A
20A 20A
10A 10A
5A
1357
9
486102
GROUND BLOCK
FUSE BLOCK
SWITCH POD
BATTERY POSITIVE
BATTERY NEGATIVE
FROM HARNESSES OR
DISTRIBUTION PANEL
