Description Part Number Qty.
1 Motor - 115 V (D)A5, (D)XA5, (D)A52, (D)XA52 210K 1
Motor - 208/220-240 V (D)A54, (D)XA54, (D)A548, (D)XA548, †(D)A57, †(D)XA57 210ACEK 1
2 Motor Brush 206NL 2 Req’d
3 Motor Mounting Strap 110-4A 2 sets
4 Motor Mounting Brackets 110-4 2
5 Micro Switch Only (D)A(All) 143F 1
6 Switch Timer Unit - 115 V, 30 Seconds (D)A5, (D)A52 225 1
Switch Timer Unit - 208-230 V, 30 Seconds (D)A54 225A 1
Switch Timer Unit - 220-240 V, 50 Hz, 30 Seconds (D)A548 225M 1
Switch Timer Unit - 277 V, 30 Seconds (D)A57 225A7 1
7 Cover Complete, Cast Iron, Automatic, White XA(All)* 70XA5-974AK 1
Cover Complete, Cast Iron, Pushbutton, White A(All)* 70A5-974AK 1
Cover Complete, Steel, Automatic, White DXA(All)* 72DXA5-974K 1
Cover Complete, Steel, Pushbutton, White DA(All)* 72DA5-974K 1
Cover Complete, Stainless Steel, Auto/Pushbutton* Call to order 1
8 Pushbutton Retaining Ring, Insulated Push Rod Tip, and Spring Kit (D)A(All) 193K 1
9 Security Allen Wrench 204TP 1
10 Inlet Grill, Cast Iron, Pushbutton, with Mtg. Hardware A(All) 194-1K 1
Inlet Grill, Cast Iron, Automatic, with Mtg. Hardware XA(All) 194-1BK 1
11 Tamper Proof Cover Screw, Cast Iron Covers 100B2 2
Tamper Proof Cover Screw, Steel Covers 46-330 2
Lock Washer, Steel Covers 59-005028 2
12 Nozzle Assembly Kit 34-172K 1
13 Pushbutton Adapter, Gasket and Bushing Unit (D)A(All) 190K 1
14 Pushbutton Assembly Kit (Knob, Rod, Ring, Spring and Tip) (D)A(All) 185K 1
15 Blower Scroll Half with Base Mount and Thermostat 211PK 1
16 Blower Plastic 101P 1
17 Blower Scroll Half with Terminal Block - Left Side 112P 1
18 Heating Element - 115 V, 20 AMP (D)A5, (D)XA5 213 1
Heating Element - 115 V, 15 AMP (D)A52, (D)XA52 213B 1
Heating Element - 230 V (D)A54, (D)XA54, (D)A548, (D)XA548 213A4 1
Heating Element - 277 V, 8.5 AMP (D)A57, (D)XA57 213A7 1
19 Grid, Ground Assy (All) 12-001 1
20 Thermostat Only 3/4” 1111-03 1
r
Automatic Sensor Control - 115 V (D)XA 16-230-120 (D)A 1
r
Automatic Sensor Control - 208-230 V (D)XA54 16-240-208 (D)A 1
r
Automatic Sensor Control - 220-240 V, 50Hz CE Only (D)XA548 16-230-240 CE 1
r
Infrared Sensor, Eye (D)XA(All) 49-238 1
* Specify model when ordering.
(†) 277 Volt Models Use 210ACEK Motor (230 V Power Tap).
r Not shown.
