CS200 Control Systems
8
General Information
User Interface
Display Type Vacuum Fluorescent Display (VFD)
Buttons 11
Level, Temperature and Alarm Information VFD
“At a Glance” status LED status wheel
Filling 1 LED
Menu Access 1 LED
Language English and German
Control Tests
Power Up Self-Test Control system check
Thermistor Status Yes
Battery voltage Yes
Control voltages Yes
Temperature circuit Yes
Alarms
Low Level Alarm Always enabled
High Level Alarm Always enabled
Sensor Error Alarm Always enabled
High Temperature Alarm (T/C #1, T/C #2) Programmable
Low Temperature Alarm (T/C#1, T/C#2 ) Programmable
Thermocouple Calibration Alarm Always enabled
Thermocouple Open Alarm Always enabled
Power Failure (Remote only) Always enabled
Low LN
2
Supply Alarm Programmable
Battery Mode Warning Always enabled
Lid Open Too Long Alarm Programmable
Valve Stuck Open Alarm Programmable
Unauthorized Access Warning Programmable
LN
2
Use Warning Programmable
Low Battery Voltage Always enabled
Audible Alarm Always enabled
Audible Alarm Re-trigger Programmable
Visual Alarm Indicator Always enabled
Remote Alarm Delay Programmable
CS200 SERIES Control System Specifications (cont’d)
