CS200 Control Systems
Buttons
Power Turns power on/off
Fill/Defog Open Valve
Stop Close Valve
Menu Access Menu
Mute Silence audible
Enter Save a setting or select a menu choice
Back/Exit Leave a setting unchanged or back out of menu.
Up arrow Scroll the menu system or increase a value
Down arrow Scroll the menu system or decrease a value
Left arrow Scroll horizontal menu
Right arrow Scroll horizontal menu
Data Collection
Temperature Yes
Level Yes
Alarms Yes
Memory 4 Mb
Dimensions
Display Width 9.5” (241 mm)
Display Height 2.0” (50.8 mm)
Display Depth 1.31” (33.3 mm)
Display Weight .625 lbs (.28 kg)
Main Control Width 8.875” (225.4 mm)
Main Control Height 6.688” (169.9 mm)
Main Control Depth 1” (25.4 mm)
Main Control Weight 1.0 lbs (.45 kg)
Battery Width 7.25” (184.2 mm)
Battery Height 6.375” (161.9 mm)
Battery Depth 3.25” (82.6 mm)
Battery Weight 12.4 lbs (5.6 kg)
General Information
CS200 SERIES Control System Specifications (cont’d)
NOTE: Above measurements are for LABS; CS200 controllers are integrated into all K Series models.
