Brush Cutter Attachment EN
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTEND USE
This attachment is intended for cutting thick brush.
ASSEMBLY & OPERATION
Action Figure
ASSEMBLY
Connecting
Remove the existing attachment, and
connect the pole hedge trimmer. Slip
the attachment into the shaft of the
main unit and secure in place with the
locking knob.
See Fig. A
Assembling the safety-stop handle
Loosen the screw on the auxiliary
handle, insert the safety-stop handle,
then tighten the screw to make sure it
is well fixed.
See Fig. B
Assembling the shoulder strap
See Fig. C
Assembling the safety guard
Align the holes, then tighten three
screws on the safety guard.-
See Fig. D
Assembling the brush cutter blade
Insert the hex key into the hole. Place
washer on top of the safety guard, place
brush-cutter blade on top of the washer,
place cover over brush-cutter blade.
After that, use the wrench to tighten the
lock-nut.
See Fig.
E1, E2
OPERATION
Starting
Press the lock-off button first, then press
the switch trigger to start the machine.
See Fig. F
MAINTENANCE
Remove the battery from brush cutter
attachment before carrying out any
adjustment, servicing or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep
the motor ventilation slots clean. Keep all working
controls free of dust.
FOR BATTERY TOOLS
The ambient temperature range for the use and
storage of tool and battery is 0℃-45℃ (32°F-113°F).
The recommended ambient temperature range for
the charging system during charging is 0℃-40℃
(32°F-104°F).
