2-in-1 cordless Li-ion grass trimmer/edger
EN
1. REAR HANDLE
2. AUXILIARY HANDLE
3. TELESCOPIC SHAFT
4. LOCKING KNOB
5. AUXILIARY HANDLE LOCKING LEVER
6. SAFETY GUARD
7. SPACER GUARD
8. EDGER WHEEL
9. LINE CUTTER
10. BATTERY PACK
11. CUTTING HEAD COVER (SEE FIG M2)
12. CAP RELEASE LATCH (SEE FIG M2)
13. SPOOL (SEE FIG M2)
14. CUTTING HEAD (SEE FIG M2)
15. EYELET (SEE FIG M2)
16. LINE FEED BUTTON (SEE FIG M1)
17. CHARGER (SEE FIG C)
18. CHARGED INDICATOR LIGHT (GREEN) (SEE FIG D)
19. CHARGING INDICATOR LIGHT (RED) (SEE FIG D)
* Not all the accessories illustrated or described are included in standard delivery.
