6
1. AUXILIARY HANDLE
2. LOCK OFF BUTTON
3. ON/OFF SWITCH
4. BATTERY PACK
5. SAFETY GUARD
6. FLOWER GUARD
7. LINE CUTTER
8. SPOOL COVER (See Fig. G2)
9. CAP RELEASE LATCH (See Fig. G2)
10. SPOOL (See Fig. G2)
11. TRIMMER HEAD (See Fig. G2)
12. EYELET (See Fig. G2)
13. LINE FEED BUTTON (See Fig. G1)
Not all the accessories illustrated or described are included in standard delivery.
