Cordless Hedge Trimmer EN
11
ASSEMBLY & OPERATION
ACTION FIGURE
BEFORE USING YOUR CORDLESS
HEDGETRIMMER
Assembling the safety guard See Fig. A
Assembling the front handle
NOTE : The handle is designed to
prevent being assembled in wrong
direction . If you find it cannot be
installed, please turn it around.
See Fig.
B1, B2
Checking the battery charge condition
NOTE : Fig. C only applies for the
battery pack with battery indicator light.
See Fig. C
Charging the battery pack
NOTE :
• The batteries are shipped
uncharged. Each battery must be
fully charged before the first use.
• Always fully charge the two
batteries at same time. More details
can be found in charger’s manual.
See Fig. D
Installing and Removing the battery
pack
NOTE :
• This machine will only run
when 2 batteries are installed.
It is recommended to use the
same two batteries and charge
the two batteries at the same
time.
• When you use two batteries
with different power, the
machine will only run to the
lower common denominator.
See Fig. E
OPERATION
Power indicator light
See details in BATTERY STATUS part
IMPORTANT:
When only one light is illuminated,
your battery is overly discharged,
even though the trimmer may still
be capable of hedge trimming.
Continuing to operate your
trimmer with the battery in this
discharged condition may reduce
the life and performance of your
battery.
When no light is illuminated,
at least one battery is not fully
installed or battery may be
defective, please double check
the batteries are fully seated into
position.
See Fig. F
Remove the blade sheath See Fig. G
Starting and stopping
See Fig.
H1, H2
Rotating rear handle
NOTE :
• Unlock the locking switch before
rotating.
• After rotating the handle to the
desired position, adjust it a little
until a click can be heard.
WARNING:
• Always make sure that the
handle is locked in the desired
position before operation.
• Always make sure the locking
switch is locked before starting
the hedge trimmer.
See Fig.
I1, I2
Top cutting
WARNING: If any parts are
missing, damaged or broken, do
not operate your hedge trimmer until
all damaged parts have been replaced
or repaired. Failure to do so could result
in serious personal injury. DO NOT
USE WITHOUT FRONT HANDLE AND
SAFETY GUARD.
See Fig. J
Side cutting
WARNING: Stop operating the trim-
mer before rotating the handle.
See Fig.
K1, K2
Lubricating the Cutting Blade
NOTE : It is important to use only the
recommended standard lubricating oil
(WD-40) to avoid damage to the blade.
See Fig. L
To store your hedge trimmer
See Fig. M
HOW TO USE YOUR HEDGE
TRIMMER
Before cutting an area, inspect it first and remove
any foreign objects that could become thrown or
entangled in the blades. Always hold the trimmer
with both hands and with the blade away from you
before turning it on.
When trimming new growth, use a wide sweeping
action so that the stems are fed directly into the
blade.
Allow the cutting blades to reach full speed before
cutting. When operating, keep the cutting blades
away from people and objects such as walls, large
stones, trees, vehicles, etc.
If the blade stalls, immediately stop the trimmer.
Release the two Switch Levers before attempting to
clear jammed debris from the cutting blades.
Wear gloves when trimming thorny or prickly growth.
Do not attempt to cut stems that are too thick for the
cutting blade.
