All-in-one Blower/Vac/Mulcher EN
1110
SYMBOLS
ASSEMBLY
ASSEMBLING THE BLOWER/VACUUM
TUBE (Fig. A, B)
Before assembling the Blower/Vacuum Tube,
be sure the on/off switch (2) is in position ‘’O’’.
Fit the Blower/Vacuum Tube to the motor
housing as shown in Fig. A and B. Check the
Blower/Vacuum Tube is firmly secured.
WARNING! Do not attempt to operate
or disable the safety switch by any
means other than the normal assembly or
removal of the cover.
NOTE: After assembling the Blower/Vacuum
Tube, you may disassemble the blower by
moving the On/Off switch (2) to position ‘’O’’.
Then press the Release Button (3), so that you
can separate the tube. Do not try to separate
the tubes by force or by using tools.
ATTACHING THE DEBRIS COLLECTION
BAG (Fig. C)
The vacuum is equipped with a Debris
Collection Bag (10), which is designed for
collecting leaves and debris. Attach debris bag
as show in Fig C
–Align debris bag housing slots with the
locking pins
—push up into position, then rotate the debris
housing counter-clockwise
–ensure the debris bag is fully secured
OPERATION
CONNECTING TO A POWER SOURCE
Use only a polarized (i.e., one blade is wider
than the other), UL listed (CSA certified in
Canada) extension cord recommended for
outdoor use. A polarized plug will fit in a
polarized cord only one way. If the plug does
not fit fully in the cord, reverse the cord. If it
still does not fit, purchase a polarized extension
cord. Do not change the plug in any way.
Extension Cord
Length
Minimum Wire
Gage (A.W.G.)
100 ft. 14
150 ft 12
Double insulation
