16
SUGGESTED BATTERIES AND
CHARGERS
Category Model Capacity
20V Battery
WA3525 2.0Ah
WA3575 2.0Ah
20V Charger
WA3742 0.4A
WA3881 2.0A
We recommend that you purchase your accessories listed
in the above list from the same store that sold you the tool.
Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
4.OPERATING INSTRUCTIONS
NOTE Before using the tool, read the instruction
book carefully.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing & Installing the battery pack See Fig. A1
Charging the battery pack See Fig. A2,
ASSEMBLY
CHUCK ADJUSTMENT
WARNING: Always lock off trigger switch and
disconnect tool from power source when changing
accessories. Always ensure the bit is secure before starting
the tool. Damage to the Chuck or a loose bit may cause
possible personal injury.
--Removing the bits See Fig. B1
--Inserting the bits See Fig. B2
-- Assembling the belt hook
See Fig. C1,
C2
OPERATION
FORWARD/REVERSE ROTATION
CONTROL
WARNING: Never change the
direction of rotation when the
chuck is rotating, wait until it has stopped!
See Fig.D1,
D2,D3
TWO-SPEED GEAR CONTROL See Fig. E
