Worx WX317 Safety And Operating Manual

5
4
Impact drill WX317 WX318
1. KEYLESS CHUCK
2. DEPTH GAUGE
3. DRILL/HAMMER DRILL FUNCTION
SELECTOR
4. SWITCH LOCK ON BUTTON
5. ON/OFF SWITCH
6. VARIABLE SPEED CONTROL
7. FORWARD AND REVERSE ROTATION
CONTROL LEVER
8. AUXILIARY HANDLE
Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX317 WX318 (300-329-designation of
machinery, representative of Impact Drill)
WX317 WX318
Voltage
230-240V~50Hz
Power input
600W 810W
No load speed
0-3000/min
Impact rate
0-48000/min
Chuck capacity
13mm
Drilling
capacity
Masonry
13mm 16 mm
Wood
25mm 32 mm
Steel
13mm 13 mm
Protection class
/II
Machine weight
1.6kg 2.42kg
ACCESSORIES
WX317 WX318
Auxiliary handle 1 1
Depth gauge 1 1
HSS drill bit /
3 (5mm, 6mm,
8mm)
Masonry drill bit /
3 (6mm, 8mm,
10mm)
We recommend that you purchase your accessories
from the same store that sold you the tool. Use good
quality accessories marked with a well-known brand
name. Choose the type
according to the work you intend to undertake. Refer
to the accessory packaging for further details. Store
personnel can assist you and offer advice.
ORIGINAL INSTRUCTIONS
GENERAL POwER TOOL
SAFETY wARNINGS
WARNING: Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
1. WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d)
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current
device (RCD) protected supply. Use of an
RCD reduces the risk of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may

Worx WX317 Specifications

General

Input power	600 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz
Impact rate	48000 bpm
Rated speed (max)	3000 RPM
Drilling diameter in wood (max)	25 mm
Drilling diameter in concrete (max)	13 mm
Carrying case	Yes
Product color	Black, Orange

Weight and Dimensions

Weight	2100 g
