Worx WX354 User Manual

20V Brushless Impact Drill
EN
TECHNICAL DATA
Type WX354 WX354.1 WX354.9 (3-designation
of machinery, representative of Battery-
powered Drill)
COMPONENT LIST
1. CHUCK
2. TORQUE ADJUSTMENT RING
3. FUNCTION MODE SELECTION SWITCH
4. TWO-SPEED GEAR CONTROL
5. FORWARD/REVERSE ROTATION CONTROL
6. SOFT GRIP HANDLE
7. BATTERY PACK *
8. BELT HOOK
9. BATTERY PACK RELEASE BUTTON *
10. SIGHT LIGHT
11. ON/OFF SWITCH
12. BIT CLIP
13. BATTERY CAPACITY INDICATOR *
* Not all the accessories illustrated or
described are included in standard delivery.
**Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
11
NOISE INFORMATION
A weighted sound pressure L
pA
: 88.4dB(A)
A weighted sound power L
wA
: 99.4dB(A)
K
PA
& K
WA
5.0dB(A)
Wear ear protection.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 62841:
Drilling
into
metal
Vibration emission value
a
h,D
= 4.315m/s²
Uncertainty K = 1.5m/s²
Impact
drilling
into
concrete
Vibration emission value
a
h,ID
= 10.204m/s²
Uncertainty K = 1.5m/s²
The declared vibration total value and the declared
High speed
Low speed
Lock
Waste electrical products must not be
disposed of with household waste.
Please recycle where
facilities exist. Check with your local
authorities or retailer for recycling
advice.
WX354
WX354.1
WX354.9
Rated
voltage 20V Max**
No
load speed 0-600/0-2000/min
Impact
rate 0-1800/0-6000bpm
Clutch
setting
positions
18+1+1
Max
torque 60N.m
Chuck
capacity 13mm
Max.
drilling
capacity
Steel
13mm
Wood
40mm
Brickwork
16mm
Concrete
10mm
Machine
weight 1.8kg 1.8kg 1.4kg
