20V Brushless Impact Drill
FUNCTION MODE
SELECTION
SCREWDRIVING,
DRILLING,
HAMMER
See Fig. F1, F2, F3
ADJUSTMENT
See Fig. G
the on/off
WARNING:
Do not
operate for long periods
at low speed because excess
heat will be produced
internally.
See Fig. H
LED light indicator (See Fig. H)
Before operation, the LED light will be activated
when the On/Off switch is slightly depressed, and
will automatically turn off 20 seconds after the On/Off
switch is released.
WARNING:
To turn on the light, press the On/
Off
switch and
make sure the
Forward/Reverse
Rotation Control is on right/left position.
The tool and battery are equipped with a protection
system. When the LED Light is quickly flashing 60
seconds and turn off, the system will automatically
cut off power to the tool to extend battery life.The
tool will automatically stop during operation if the
tool and/or battery are placed under one of the
following conditions:
• Overloaded:The tool is operated in a manner that
causes it to draw an abnormally high current. In this
situation, release theTrigger Switch on the tool and
stop the application that caused the tool to become
overloaded.Then pull theTrigger Switch again to
restart.
•
Overheated:
Under the condition above, if the tool
does not start, theTool and Battery are overheated.
In this situation, let theTool and Battery cool before
pulling theTrigger Switch again.
• Low battery voltage: The remaining Battery
capacity is too low and the tool will not operate. In
this situation, remove and recharge the Battery.
PROBLEM
SOLUTION
1. WHY DOES THE DRILL NOT TURN ON WHEN
YOU PRESS THE SWITCH?
The Forward and Reverse Switch, which is on top of
the trigger, is positioned in the lock function. Unlock
the Forward and Reverse Switch putting it into the
required rotation position. Push the trigger and the
drill will start to rotate.
2. THE DRILL STOPS BEFORE THE SCREW IS
COMPLETELY TIGHTENED. WHY?
Verify the torque position of the Torque Adjustment
Ring, you can find the Torque Adjustment Ring
between the Chuck and the drill body. Position
1 is the lowest torque (screw driving force) and
position 18 is the highest torque (screw driving
force). Position is for drill operation. Position
is for hammer drill operation. Regulate the Torque
Adjustment Ring to a higher position to reach the
best result (See G).
3. I CAN NOT FIT THE BATTERY INTO THE
BATTERY CHARGER. WHY?
The battery can be inserted into the charger only in
one direction. Turn the battery around until it can be
inserted into the slot, the red LED Light should turn
on when the battery is charging.
4. REASONS FOR DIFFERENT BATTERY PACK
WORKING TIMES
Charging time problems, as above, and having not
used a Battery Pack for a prolonged time will reduce
the Battery Pack working time. This can be corrected
after several charge and discharge operations by
charging & working with your drill. Heavy working
conditions such as large screws into hard wood will
use up the Battery Pack energy faster than lighter
working conditions. Do not re-charge your Battery
Pack below 0
o
C and above 40
o
C as this will affect
performance.
MAINTENANCE
Remove the Battery Pack from the tool before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication
13
or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep
the motor ventilation slots clean. Keep all working
controls free of dust. Occasionally you may see
sparks through the ventilation slots. This is normal
and will not damage your power tool.
For Battery tools
The ambient temperature range for tool and battery
use and storage is 0
o
C-45
o
C.
The recommended ambient temperature range for
the charging system during charging is 0
o
C-40
o
C.
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
local authorities or retailer for recycling advice.
