Worx WX372 Safety And Operating Manual

7
6
WX372 WX372.1
WX372.9
Lithium-Ion cordless
hammer drill
technical data
Type WX372 WX372.1 WX372.9 (3-designation of machinery, representative of
hammer drill)
WX372 WX372.1 WX372.9
Rated voltage 20V Max**
No load speed 0-550 / 0-1800/min
Impact rate 0-8800 / 0-28800/min
Number of clutch position 22+1+1
Max torque 50N.m
Chuck capacity 13mm
Max. drilling capacity
Steel 13mm
Wood 40mm
Brickwork 16mm
Concrete 13mm
Machine weight 1.65kg 1.29kg
**Voltage measured without workload. Initial battery voltage reaches Maximum of 20volts.
Nominal voltage is 18volts.
accessOries
WX372 WX372.1 WX372.9
60min Charger 1 1 /
2.0Ah Li-Ion Battery Pack 2 1 /
Double Ended Bit 1 1 1
We recommend that you purchase your accessories from the same store that sold you the
tool. Use good quality accessories marked with a well-known brand name. Choose the type
according to the work you intend to undertake. Refer to the accessory packaging for further
details. Store personnel can assist you and offer advice.

Worx WX372 Specifications

General

Power source	Battery
Charging time	60 min
Battery voltage	20 V
Battery capacity	2 Ah
Battery included	Yes
Number of batteries included	2 pc(s)
Chuck type	Keyless
Motor type	Brushed
Screwdriving	-
Product design	Pistol grip drill
Torque (max)	50 N⋅m
Number of gears	22
Idle speed (max)	1800 RPM
Idle speed (min)	550 RPM
Chuck capacity (max)	13 mm
Impact rate (high speed)	28800 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in concrete (max)	12 mm
Product color	Black, Orange, Silver

Weight and Dimensions

Depth	66 mm
Width	216 mm
Height	189 mm
Weight	1650 g
