OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
INTENDED USE (FOR WX175 WX175.1)
The machine is intended for driving in and loosening screws as well as for drilling in wood,
metal and plastic.
INTENDED USE (FOR WX373 WX373.1 WX373.2)
The machine is intended for impact drilling in brick, concrete and stone as well as for drilling
in wood, metal and plastic. Machines with electronic control and right/left rotation are also
suitable for thread-cutting.
ASSEMBLY AND OPERATION
ACTION FIGURE
BEFORE OPERATION
Checking the battery charge condition See Fig. A1
Removing the battery pack See Fig. A2
Charging the battery See Fig. A3
Installing the battery pack See Fig. A4
ASSEMBLY
CHUCK ADJUSTMENT
WARNING: Always lock off trigger switch and disconnect tool from power source when
changing accessories. Always ensure the bit is secure before starting the tool. Damage to the
Chuck or a loose bit may cause possible personal injury.
-- Removing the bits See Fig. B1
-- Inserting the bits See Fig. B2
Assembling the belt hook and bit clip See Fig. C1, C2, C3, C4
OPERATION
FORWARD/REVERSE ROTATION CONTROL
WARNING: Never change the direction of rotation when the
chuck is rotating, wait until it has stopped!
See Fig.D1, D2, D3
TWO-SPEED GEAR CONTROL
See Fig. E
TORQUE ADJUSTMENT
SCREWDRIVING, DRILLING, HAMMER DRILLING
See Fig. F1, F2, F3
