TECHNICAL DATA
Type
WX175 WX175.1( 1 - designation of machinery, representative of Battery-powered Drill)
WX373 WX373.1 WX373.2 (3- designation of machinery, representative of Hammer Drill)
WX175 WX175.1 WX373 WX373.2 WX373.1
Charger voltage 100-240V ~50/60Hz
Rated voltage 20V Max**
No load speed 0-600/0-2000/min
Impact rate / 0-9600/0-32000BPM
Number of clutch position 18+1 22+1+1
Max torque 60N.m
Chuck capacity 13mm
Max. drilling
capacity
Steel 13mm
Wood 40mm
Brickwork / 16mm
Concrete / 13mm
Machine weight 1.55kg 1.83kg 1.58kg 1.85kg
** Voltage measured without workload. Initial battery voltage reaches maximum of
20 volts. Nominal voltage is 18 volts.
1. CHUCK
2. TORQUE ADJUSTMENT RING
3. TWO-SPEED GEAR CONTROL
4. FORWARD/REVERSE ROTATION CONTROL
5. SOFT GRIP HANDLE
6. BATTERY PACK *
7. BELT HOOK
8. BATTERY PACK RELEASE BUTTON
9. SIGHT LIGHT
10. ON/OFF SWITCH
11. BIT CLIP
12. BATTERY CAPACITY INDICATOR
