9
Incorrect
Correct
TPI
Teeth per inch
POSITEC Inc. has established a partnership with
the RBRC Corporation to recycle any Positec
batteries with the RBRC-call2recycle seal. For
environmental protection, please do not discard
batteries in the trash. After the batteries’ life cycle
is ended, please call 1-800-822-8837 for a free
service that will properly dispose of the battery.
COMPONENT LIST
1. BLADE*
2. LED LIGHT
3. HAND GRIP AREAS
4. LOCK-OFF BUTTON
5. BATTERY PACK RELEASE BUTTON*
6. BATTERY PACK*
7. ON/OFF TRIGGER SWITCH
8. PENDULUM ACTION CONTROL
9. BLADE CLAMP RELEASE LEVER
10. ADJUSTABLE PIVOT FOOT PLATE
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX508L WX508L.9(500- 519-designation
of machinery, representative of Reciprocating
Saw)
WX508L WX508L.9
Voltage 20V Max**
No-load speed 0-3000/min
Stock length 7/8 inch
Cutting
capacity
Wood 7 inch
Steel 15/32 inch
PVC pipe 3 inch
Pendulum position 4
Machine Weight 5.7lbs 4.9lbs
** Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
ACCESSORIES
WX508L WX508L.9
Blade for wood 1 1
Blade for steel 1 1
Battery pack 1 /
Charger
1 /
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
Only use the appropriate accessories intended for
this tool. Accessory information can be found on
the product packaging, at a WORX dealer or on our
website at www.worx.com.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY AND OPERATION
ACTION FIGURE
Removing The Battery Pack See Fig. A1
Charging The Battery Pack See Fig.A2
