1. ON/OFF SWITCH
2. LOCK-OFF BUTTON
3. HAND GRIP AREAS
4. CHIP DEFLECTOR LEVER
5. DUST EXTRACTION
6. BASEPLATE STAND (SEE FIG E)
7. BLADE CLAMP (SEE FIG F)
8. BLADE (SEE FIG F) *
9. GUARD (SEE FIG F)
10. CUTTING DEPTH ADJUSTMENT
11. BELT COVER
12. SMALL PULLEY (SEE FIG G)
13. LARGE PULLEY (SEE FIG G)
14. BASEPLATE
15. V-GROOVE
16. DEPTH GAUGE(SEE FIG I) *
17. PARALLEL GUIDE(SEE FIG K) *
* Not all the accessories illustrated or described are included in standard delivery.
Planer EN
