1. ON/OFF SWITCH
2. LOCK-OFF SWITCH
3. HAND GRIP AREAS
4. CUTTING DEPTH ADJUSTMENT
5. DUST EXTRACTION
6. BASEPLATE STAND (See Fig. D)
7. BLADE CLAMP (See Fig. F)
8. BLADE (See Fig. F) *
9. PLANING DEPTH SCALE
10. SCREW (See Fig. F)
11. BELT COVER
12. PINION (See Fig. H)
13. LARGE PULLEY (See Fig. H)
14. BASEPLATE
15. V-GROOVES
16. REBATE DEPTH GAUGE
17. FASTENING BOLT
18. PERPENDICULAR FENCE
19. SPANNER (See Fig. F)
20. BRUSH CAPS (See Fig. J)
21. PLANER BASE T-SLOT
* Not all the accessories illustrated or described are included in standard delivery.
