Finishing Sander WX641 WX642
SYMBOLS
To reduce the risk of injury, user must
read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
RCM marking
ABN: Australian Business Number. By
this number, business information such
as entity type, status, business location
etc. can be found at website http://abr.
business.gov.au.
ABN of Positec Australia Pty Limited is
14 101 682 357
1. SLIDING ON-OFF SWITCH
2. SOFT GRIP HANDLE
3. DUST BOX*
4. DUST EXTRACTION OUTLET
5. CLAMP LEVER
6. CLAMP LEVER LOCK
7. BASE PLATE
8. SANDING PAPER CLAMP
9. VARIABLE SPEED CONTROL (ONLY FOR
WX642)
10. PAPER PUNCH*
11.
DUST EXTRACTION ADAPTER (A: INNER
DIAMETER 35mm B: INNER DIAMETER 32mm)*
12. SANDING PAPER* (See Fig. A)
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WX641 WX642 (635-644-designation of
machinery, representative of finishing sander)
WX641
WX642
Voltage 230-240V~50Hz
Power Input 250W 270W
No-load speed 12000/min 6000-12000/min
Base size 90x187mm
Orbital diameter 1.6mm
Protection class
/ll
Machine weight 2.0kg
ACCESSORIES
WX641
WX642
Paper hole punch 1 1
dust box 1 1
working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5. SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.

Worx WX641 Specifications

General

Product color	Black
Type of sander	-
Power	250 W
Maximum paper size	93 x 230 mm
Idle oscillation rate (max)	12000 OPM
Number of sandpapers	6
Power source	AC

Weight and Dimensions

Weight	2000 g
Sanding plate size (WxD)	90 x 187 mm
