32mm dust extraction adaptor 1 1
35mm dust extraction adaptor 1 1
60 grit clamp sanding paper 2 3
80 grit clamp sanding paper 2 3
120 grit clamp sanding paper 2
3
If using sanding paper without dust holes, you
must use the paper punch to make holes.
Use 1/3 sheet sanding paper of the following
size:
Sanding Paper size:
93*230mm for no hook & loop (Clamp only)
93*182mm for hook & loop
We recommend that you purchase your accessories
from the same store that sold you the tool. Use good
quality accessories marked with a well-known brand
name. Choose the type according to the work you
intend to undertake. Refer to the accessory packaging
for further details. Store personnel can assist you and
offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE:
The machine is intended for dry sanding of wood,
plastic, filler and coated surfaces.The sander is not to
be used for plastering.
ASSEMBLY AND OPERATION
Action Figure
ASSEMBLY
Fitting &Removing the
Sanding Paper
See Fig. A1, A2
Paper Punch (Optional) See Fig. B
Attaching the Dust Box
Caution: To prevent
the possibility of
sanding dust or foreign
body being thrown into your
face or eyes, never attempt to
use your sander without the
dust box properly installed.
See Fig. C
Emptying the Dust Box
-For more efficient operation,
empty dusts box every
5-10mins.
See Fig. D1, D2
Using the Dust Extraction
Adapter
See Fig. E, F
OPERATION
Plugging in the power See Fig. G
Switching On/Off See Fig. H
Variable speed control (only
for WX642)
See Fig. I
WORKING HINTS FOR YOUR
FINISHING SANDER
If your power tool becomes too hot, especially when
used at low speed, set the speed to maximum and run
it with no load for 2-3 minutes to cool the motor. Avoid
prolonged usage at very low speeds. Always use sand
paper that is suitable for the material you want to sand.
Always ensure the work-piece is firmly held or
clamped to prevent movement.
Any movement of the material may affect the quality
of the sanding finish.
Start your sander before sanding and turn it off only
after you stop sanding. For the best results, sand
wood in the direction of the grain.
Do not start sanding without having the sandpaper
fitted.
Do not allow the sandpaper to wear away it will
damage the base-plate. The guarantee does not cover
base-plate wear and tear.
Use coarse grit paper to sand rough surfaces,
medium grit for smooth surfaces and fine grit for the
final surfaces. If necessary, first make a test run on
scrap material.
Use only good quality sandpaper.
The sandpaper controls the sanding efficiency, not
the amount of force you apply to the tool. Excessive
force will reduce the sanding efficiency and cause
motor overload. Replacing the sandpaper regularly
will maintain optimum sanding efficiency.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication
or maintenance. There are no user serviceable parts
in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with
a dry cloth. Always store your power tool in a dry
place. Keep the motor ventilation slots clean. Keep
all working controls free of dust. Occasionally you
may see sparks through the ventilation slots. This
is normal. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
