6
1. VARIABLE SPEED CONTROL
2. ON/OFF SWITCH
3. SWITCH LOCK-ON BUTTON
4. HAND GRIP AREAS
5. DUST BAG
6. DUST EXTRACTION OUTLET
7. BELT TENSION RELEASE LEVER
8. ROTATION DIRECTION ARROW
9. BELT CENTERING CONTROL KNOB
10. FRONT HANDLE
11. SANDING BELT (See Fig D)
*
12. BASE-PLATE (See Fig D)
13. DUST EXTRACTION ADAPTER (See Fig F,G)
*
Not all the accessories illustrated or described are included in standard delivery.
