13
5-in-1 Multi Sander
EN
185*95mm
Finishing
sanding paper
3 3 3
125mm
Random orbit
H&L
sanding paper
3 3 3
140*90mm
Detail H&L
sanding paper
3 3 3
76*30mm
Finger H&L
sanding paper
3 3 3
100*50mm
Contour H&L
sanding paper
3 3 3
We recommend that you purchase your accessories from
the same store that sold you the tool. Refer to the accessory
packaging for further details. Store personnel can assist you
and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE:
This machine is intended for dry sanding of wood,
plastic, filler and coated surfaces. The sander is not to
be used for plaster or spackle.
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLY
Fitting &Replacing the Sanding Plate
Note: Read and understand the instructions
before assembling or changing sanding plates.
Note: Open the Hyperlock lever completely
when attaching or removing a sanding plate.
Note: When assembling the finishing plate/
detail plate, first check the assembling direction.
WARNING!The sanding plate must
be attached before starting the
sander.
WARNING! Avoid pinching hands
and fingers when using the
hyperlock™.
WARNING! Do not touch the
bottom fan after use to avoid
high-temperature burns.
See Fig.
A1-A8
Fitting the Sanding Paper
See Fig.
B1-B6
Attaching the Dust Bag
Caution:
To prevent the possibility of dust or a
foreign body being thrown into your face or
eyes, never attempt to use your sander without
the dust bag properly installed.
See Fig. C
Charging the Battery Pack
See Fig.
D1,D2,D3
Installing the Battery Pack
See Fig. E
OPERATION
Switching On/Off
See Fig. F
Using the Variable Speed Dial (Speed
settings 1-6)
- The Variable Speed Dial can be used to set the
optimum speed according to the sanding plate
used and the respective application.
See Fig. G
Application
Sanding
paper
Speed
Sanding down
varnishes
180…400 3-6
Sanding paint 40…120 4-6
Touching up
paintwork
120…240 1-5
Sanding wood 60…240 1-6
Machining
veneer
180…240 3-5
Derusting metal 40…120 4-6
Sanding metal
and steel
120…240 4-6
Sanding curved
surface
60…240 1-6
Removing the Battery Pack
See Fig. H
Emptying the Dust Bag
-For more efficient operation, empty dusts bag
every 5-10 mins.
See Fig. I1-I2
WORKING HINTS FOR YOUR
MULTI SANDER
If your power tool becomes too hot, especially when
used at low speed, set the speed to maximum and
run it with no load for 2-3 minutes to cool the motor.
Avoid prolonged usage at very low speed. Always
use sand paper that is suitable for the material you
