Cordless mini cutter EN
1110
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction
book carefully.
INTENDED USE
The machine is intended for cutting flexible, soft
materials of up to 6 mm in thickness, such as carpet, PVC,
cardboard, leather, fabrics and similar materials.
ASSEMBLY
1. CHANGING THE TOOL (See Fig. A1 A2)
NOTE: When changing the blade , you must insert an
object (such as a small slotted screwdriver) into the
spindle slot(13) to lock in place. (See Fig. A1)
a. Unscrew the blade screw(5).
b. Remove the blade(6).
c. Attach the new blade onto the tool holder ensure that
the ground edges of the blade face you.
d. Tighten the blade screw again.
OPERATION
1. ON/OFF SWITCH (See Fig. B)
Your switch is locked off to prevent accidental starting.
Depress lock off button then on/off switch and release
lock off button. Your tool is now on. To switch off just
release the on/off switch.
2. CHARGING THE BATTERY
The battery charger supplied matches to the Li-ion
battery installed in the machine. Do not use other battery
chargers.
The Li-ion battery is protected against deep discharging.
When the battery is empty, the machine is switched off
by means of a protective circuit: the blade no longer
move.
In a warm environment or after heavy use, the battery
pack may become too hot to permit charging. Allow time
for the battery to cool down before recharging.
3. CHARGING
Plug charger plug into a suitable power outlet and
afterwards plug your tool into the battery charger, the
charging indicator (red) will illuminate at this time.
The charger indicator will turn into green when charging
is complete, then unplug the charging plug from the wall
socket and then remove the tool from the battery charger.
IMPORTANT: During the charging procedure, the
handle of the machine warms up. This is normal.
When not using for extended periods, disconnect the
battery charger from the socket.
Do not use the machine during the charging procedure.
WORKING INSTRUCTIONS
Do not strain the machine so heavily that it comes
to a standstill.
The cutting performance of the machine depends on the
materials to be cut and on the charging condition of the
battery.
When the load on the machine is too high, the battery
charge-control indicator can light up red. When the load
is relieved and the machine returns to the normal load
range, the indicator will light up green again.
Depending on the charge condition of the battery,
excessive feed considerably reduces the performance
capability.
Always keep the blade free and clean of material
remainders.
The guide edge (7) may not become wedged during
cutting and must be aligned parallel to the cutting
surface.
Thin materials, such as fabrics, can be pulled into the
machine during cutting and become wedged. Therefore,
do not apply too much pressure with such materials in
order to achieve good cutting results. During cutting,
apply sufficient tension while holding fabrics and cut
slowly.
Optimum cutting results are best determined through
practical testing.
MAINTENANCE
For safe and proper working, always keep the
machine clean.
While cutting, material residue can accumulate under the
blade guard.
Clean the blade guard (4) regularly using a brush or
lightly moistened cloth.
TRANSPORT
The battery has effective protection against internal
overpressure and short circuiting as well as measures
for prevention against forced rupture and dangerous
reverse current. The lithium equivalent contents
contained in the battery is below the spilling limit values.
Therefore, the battery is not subject to the national and
international regulations governing dangerous goods,
neither as individual components nor when inserted into
a machine. However, the Dangerous Goods Regulations
can be relevant when transporting several batteries.
In this case, it can be necessary to observe special
conditions (e. g. for packaging).
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your Local Authority or
retailer for recycling advice.
