WP MXMA 4800 - Default Chapter; Table of Contents



WorkshopManual01‐2013;Rev.0 1

TABLE OF CONTENTS
1 INTRODUCTION 1
2 EXPLODED VIEWS 2
3 WORK ON FORK
3.1 STANDARD SERVICE
3.1.1 DISASSEMBLING THE FORK LEGS 8
3.1.2 ASSEMBLING THE FORK LEGS 12
3.2 CARTRIDGE SERVICE
3.2.1 DISASSEMBLING THE CARTRIDGE 16
3.2.2 DISASSEMBLING THE PISTON ROD 17
3.2.3 ASSEMBLING THE PISTON ROD 17
3.2.4 DISASSEMBLING THE SCREW CAP 18
3.2.5 ASSEMBLING THE SCREW CAP 19
3.2.6 DISASSEMBLING THE COMPRESSION DAMPING 21
3.2.7 ASSEMBLING THE COMPRESSION DAMPING 21
3.2.8 SERVICE THE SCREW SLEEVE 22
3.2.9 ASSEMBLING THE CARTRIDGE 24
